SPECIFICATIONS
MONITOR
| Monitor | 9.35″ |
| Mounting Type | Clip-On rear view mirror |
| Input Voltage | 5V (12/24V accessory power adapter included) |
| Video Inputs | 1 |
| Connection Type | 2.5MM jack |
| Dimensions | 72mm(H) X 260mm(W) X 18mm(D) |
REAR CAMERA
| Mount Type | Surface Mount |
| Camera Resolution | 1080P |
| Camera Angle | 110 degree |
| Image Sensor (CMOS or CCD) | CMOS IMX323 |
| Parking Guidelines | Yes |
| IP Rating | IP65 |
| Input Voltage | 12V |
| Connection Type | Micro 4 PIN |
| Video Cable Length | 5.4M (additional 3M extension cable also available GRV90EXT, sold separately) |
| Reverese Trigger on Video Cable | Yes |
| Dimensions (Camera Only) | 19mm(H) x 24mm(W) x 22mm(L) |
RECORDING
| Number of Channels | 1 |
| Resolution | Full HD 1080P (Rear) |
| Frames Per Second | 25 (Rear) |
| Camera Angle | 110° (Rear) |
| G-Sensor | Yes |
| Super Capacitor / Battery | Super Capacitor |
| Auto Power ON/OFF | Yes |
| Microphone | Yes |
| Speaker | Yes |
| USB/Power Input | Yes (Micro) |
| Hard Wire Kit | Optional |
| Power Adaptor Voltage | 12/24V |
| Dash Cam Input Voltage | 5V 1.5A |
| Recording Modes | |
| – Continuous Loop | Yes (Seamless cycle recording) |
| – Driving Impact/Incident Detection | Yes |
| – Manual (SOS) | Yes |
| Memory Card Capacity / Class | Supports up to 128GB (card must be C6 or above, C10 is recommended) |
PRODUCT STRUCTURE
INCLUSIONS
XV9M Mirror Monitor
Rear Camera
Camera Lead with Trigger Wire
USB Cable
12/24V Charging Adapter
Mounting Screws & 3M Adhesive for butterfly camera
Mirror protector pads & rubber mounting clips
